Frame Rates | up to 1.150 fps at 720 x 576 pixel SD PAL (4:3) up to 950 fps at 1280 x 720 pixel HD 720p (16:9) up to 650 fps at 1280 x 1024 pixel MAX |
Signal Output | 8 bit tiff, avi, DPX, Create mpeg’s for proxys |
Sensor | 15 x 12mm progressive scan, CMOS Imager |
Operating System | Windows XP Professional |
Sensitivity | 160 ASA |
Internal Memory | 4 GB |
Dynamik Range | 24 bit color depth |
Lens Mount | PL-Mount |
Power | 12 V |
Weight | 3 kg |
Frame Rates | 1.500 fps in 2K 2.000 fps in 1080p 4.000 fps in 720p |
Max. Speed | 72.275 fps in 100×100 Pixels |
Signal | RAW Signal: 12 bit uncompressed WEISSCAM RAW HD Signal: 10 bit YCbCr 4:2:2 |
Signal Output | 1280 x 720p: 50p 1920 x 1080: 23,98psf, 24psf, 25psf, 29,97psf, 30psf 1920 x 1080 Dual Link: 50p, 59,94p, 60p 2K: 25p (1920 x 1080 preview)Signal Output formats vary between HD and RAW, as well as HD-SDI Single Link and Dual Link |
Sensor | Single CMOS (22,18 x 22,18 mm) |
Shutter | Global Shutter |
Sensitivity | 600 ASA |
Internal Memory | 32 GB |
Dynamik Range | 8 – 10 T-stops, up to the selected curve |
Lens Mount | Interchangeable Mount System (PL, Panavision, BNC-R, Professional, Nikon F, Canon EF, Canon FD, Leica-R, Leica-M) |
Power | 24V DC, Fischer 2/pin |
Weight | 6,8 kg |
Frame Rates | 1-340 fps @ 1920 x 1080 px, 2/3″ Sensor* 1-350 fps @ 2280 x 1280 px, Super 16** 1-350 fps @ 4096 x 2304 px, Super 35** |
Signal Output | HD 1920 x 1080 YCC 422 HD 1920 x 1080 RGB 444** RAW 10 Bit/12 Bit** (log Signal without any white balance or gain) |
Sensor | Single CMOS 2/3″, Super 16**, Super 35** |
Shutter | Global Shutter |
Sensitivity | 600 ASA* |
Dynamik Range | 12 Stops |
Lens Mount | PL Mount (exangable), other Mounts** |
Connectors | 2x T-PLUG 1x Monitor Out (BNC) 1x DC In Fischer 2 Pin |
Control | One Button / Touchscreen |
Power | 10V to 18V |
Dimensions / Weight | 205 x 130 x 110 mm (8,07 x 5,11 x 4,33 in), 2,2 kg (4,85 lbs) |
