Pure. Fast. Uncompressed.


Status Quo

… The development of T-CAM is currently on hold …

Pure Enjoy the beauty and clarity of images captured with GLOBAL SHUTTER technology.

Operate and control your T-CAM with only ONE BUTTON and the easy FILMMAKER MENU.

Fast Enhance your film by shooting exceptional high speed images additional to the standard frame rates.

Preserve exactly the same image quality over all speeds.

Uncompressed Use pure RAW data in a worldwide open standard without any compression or codec.

Maintain the highest quality and performance for grading / VFX.

Archive uncompressed files for remastering with future algorithms.

Enduring Switch to the latest sensor technology without the need to purchase a new camera!

SOHA platform, T-PLUG and the ONE HOUSING CONCEPT preserve consistent value for your T-CAM.

Flexible Operate handheld, 3D or mounted. The lightweight and compact T-CAM offers you freedom for all shooting conditions.

Select RAW or HD to work in cinematography or broadcasting with your T-CAM.

Expandable Choose between simple service and support options and different software modules for your individual requirements.

Customize your T-CAM to match very special needs and get unique functions.

Technical Data
Frame Rates 1-340 fps @ 1920 x 1080 px, 2/3″ Sensor*
1-350 fps @ 2280 x 1280 px, Super 16**
1-350 fps @ 4096 x 2304 px, Super 35**
Signal Output HD 1920 x 1080 YCC 422
HD 1920 x 1080 RGB 444**
RAW 10 Bit/12 Bit** (log Signal without any white balance or gain)
Sensor Single CMOS 2/3″, Super 16**, Super 35**
Shutter Global Shutter
Sensitivity 600 ASA*
Dynamik Range 12 Stops
Lens Mount PL Mount (exangable), other Mounts**
Connectors 2x T-PLUG
1x Monitor Out (BNC)
1x DC In Fischer 2 Pin
Control One Button / Touchscreen
Power 10V to 18V
Dimensions / Weight 205 x 130 x 110 mm (8,07 x 5,11 x 4,33 in), 2,2 kg (4,85 lbs)

* subject to change without notice
** under development

T-CAM Sample Clip

T-CAM Prototype Videos

CEO Stefan Weiss presenting T-CAM on NAB 2012, video made by www.film-tv-video.de

CEO Stefan Weiss presenting the T-CAM prototype on IBC 2011, video made by www.film-tv-video.de
